POWER QUALITY ANALYSIS

This study examines harmonics, load flow and power factor to uncover the source of electrical disturbances.

POWER FACTOR CORRECTION

This study analyzes voltage and current consumption to maximize plant efficiency and minimize poor power quality, thus reducing penalty costs from the utility.

HARMONIC ANALYSIS

This study will identify the source of harmonics to minimize potential damage to equipment and help implement corrective action.

LOAD FLOW STUDY

This study identifies overloaded and under-utilized equipment to recommend adequate sizing.

VOLTAGE DROP STUDY

This study identifies the percent of voltage drop to prevent damage to equipment and reduce wasted energy.

PROTECTIVE DEVICE COORDINATION STUDY

This study increases equipment protection, sets the devices to trip in sequence, and limits faults to smaller areas of the distribution system.

SHORT CIRCUT STUDY

This study identifies equipment before major damages occur by providing accurate fault current calculations at each location in the system.

ARC FLASH ANALYSIS

This study will determine available

fault currents and arc flash hazards, thus ensuring personnel are using the proper PPE in compliance with OSHA and NFPA.

Power Engineering Services performs engineering analyses including short circuit, protective device coordination, arc flash, harmonic analysis, load flow, motor starting, and voltage drop studies utilizing the latest engineering software.

POWER SYSTEM STUDIES
